JIS F2804 Cruciform Bollard

JIS F2804 Cruciform Bollard

  • Type: JIS F2804 Cross Bitt Bollard
  • Material: Steel plate & steel tube
  • Size: 150/200/250/300/350 mm
  • Weight: 33KG – 186KG
  • Safe Wokring Load: 25T – 90T
  • Finish: Sandblasting to S2.5 + one layer of shop primer
  • Certificate: CCS, BV, ABS, GL, NK, etc.

JIS F2804 Cruciform Bollard, also known as the Cross Bitt Bollard, is a commonly used mooring bollard on ships. It is designed and manufactured according to Japanese Industrial Standards. Its advantages are small size and easy to use, but its disadvantage is its small SWL, which is only used for small ships with steel wire ropes. Because the mooring ropes on large ships are too large to be fixed, so the bollard is not suitable for large ocean-going sailboats. It is usually used for tugboats, moorings, cargo handling, ship handling, etc.

The cruciform bollards could be made of welded steel or seamless pipe. Welding parts have no cracks, scars, holes, shrinkage, or alluvial soil such impact strength and appearance of the defects. When made of seamless pipe, the outer diameter and wall thickness shall not be less than the requirements in standards. Its size ranges from 150mm to 350mm, and its weight ranges from 33KG to 186KG.

According to the JIS F2804 standard, the cruciform bollard should be free from harmful defects, welded firmly, and the appearance strain should be as small as possible. JIS- F2804 is one of the standard configurations for ship construction issued by the Japan Standards Association. Now F2804-1976 has replaced the old F2804-1973 as the latest standard.

Boomarine is a professional supplier of marine equipment. Our mooring bollards are certified by any IACS classification society such as CCS, ABS, BV, DNV, LR, NK, etc. We can also meet your special requirements for all types of mooring equipment. If you have any needs, please feel free to contact us.

Features of JIS F2804 Cruciform Bollard:

  • Long working life, up to 15-20 years.
  • Nice shaped, good quality and with very low maintenance.
  • Strong and durable designs.
  • Can be customized according to customers’ requirements.

Dimensions: (mm)

JIS F2804 Cruciform Bollard

Dimensions

Nominal Dia. H h B D D1 D2 D3 Mass Kgs Wire Rope Dia.
150 480 280 460 165 114 206 158 33 16
200 560 320 520 216 165 256 206 60 22
250 640 360 610 267 216 308 256 102 28
300 680 380 660 318 267 360 308 154 34
350 720 420 720 355 267 400 312 186 38

Why Choose Us?

Mooring bollards are important equipment for ships. Boomarine can design and provide the best products and good services.

1. Professional sales:

  • We value every inquiry sent to us to ensure a fast and competitive quotation.
  • We cooperate with customers to bid. Provide all necessary documents.

2. On-time delivery:

  • We put your order into our tight production plan to let our customers understand the production process and ensure your on-time delivery.
  • After your order is shipped, a shipping notice/insurance will be sent to you immediately.

3. After-sales service:

  • After receiving the goods, we will accept your feedback as soon as possible.
  • We can provide installation instructions, if you need them, we can provide you with global services.
  • Our sales are 24 hours online at your request.
